Description
-
Square D
-
Type QED
-
3 Phase
-
4 Wire (Neutral Installed)
-
3000 Amp
-
480/277 Vac
-
NEMA 1 – (Indoor)
-
Switchgear / Panelboards / Panels
-
TOTAL COMBINED DIMENSIONS:
-
Height = 92 in
-
Width = 78 in
-
Depth = 36 in
-
-
MAIN LUG / WIRE PULL SECTION:
-
Bottom/Top-Fed = Bottom
-
Connection = Cable-In, Bus-Out
-
-
-
ADDONS:
-
(2) H. VIR (High Vision InfraRed Inspection Window)
-
(The following can be installed upon request: Power Metering, Surge Protection (SPD/TVSS), etc.)
-
-
INCOMING CONNECTION:
-
(10) 750 MCM – 1/0 (per phase + neutral)
-
GROUND: (1) 300 kcmil – #6
-
-
SECTION DIMENSIONS:
-
WIDTH = 24 in
-
HEIGHT = 92 in
-
DEPTH = 36 in
-
-
-
DISTRIBUTION SECTION:
-
Connection = Pass-Through Bus
-
Max Feeder = L-/P-/M-Frame (1200A)
-
Double-Row – (75 CIRCUIT)
-
-
-
INSTALLED BREAKERS:
-
N/A (breakers and blanks can be installed upon request)
-
-
ADDONS:
-
(4) H. VIR (High Vision InfraRed Inspection Window)
-
(The following can be installed upon request: ERMS (Arc Fault Reduction), Power Metering, Surge Protection (SPD/TVSS), etc.)
-
-
NEUTRAL CONNECTION:
-
(12) 750 MCM – 1/0
-
(7) 350 kcmil – #6
-
(9) 1/0 – #14
-
-
GROUND CONNECTION:
-
(1) 300 kcmil – #6
-
-
SECTION DIMENSIONS:
-
WIDTH = 54 in
-
HEIGHT = 92 in
-
DEPTH = 36 in
-
-
-
